A.3.5 GPS Connector
The installed GPS connector type is an FME female in those devices equipped with this interface.
PIN
Internal
External
A.3.6 Configuration Connector
The installed configuration connector is a DB9 female.
PIN
2
3
5
A.4 Technical Specifications
Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN Interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
Wireless LAN Interface
Teldat H1 RAIL
Signal
RF In
Gnd
Signal
RxD (Input)
TxD (Output)
GND
Motorola PowerPC MPC82xx
64 Mbytes in SDRAM
FLASH Memory (16 Mbytes)
EEPROM 2 Kbytes, NVRAM 128 Kbytes
Ethernet (802.3)
4 port switch managed through MDI/MDX autodetection
10/100 Mbps (BaseT)
M12 4 Poles Code D
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depending on the wireless WAN
version the device has incorporated.
Depending on the wireless WAN version the device has incorporated. Please see
the manual on the appropriate module.
Up to 4 coaxial connectors, type N
The antennas are supplied independently to the device
FME Connector
DB 9 Female
Technical Information
