Technical Information
A.3.4 GPS connector
The GPS connector installed is a QMA female connector.
A.3.5 Conf I/O connector
The configuration connector and the input output signals are installed in an M12 connector.
PIN
5
8
4, 6
3, 7
1, 2
A.4 Technical Specifications
A.4.1 Hardware architecture
Processor
Memory
Storage unit
26
Internal
External
PIN
Internal
External
Signal
RS232-TxD (Output)
RS232-RxD (Input)
RS232-GND
Digital Input
Digital Output (Relay)
NXP LayerScape multicore processor.
DDR4 1 GByte.
FLASH Memory 32 MBytes.
RF in/out
GND
ANT
RF in/out
GND
M12 8P A Code Female
Teldat S.A.
Teldat 5Ge-Rail Router
