Technical Information
A.3.5 GPS Connector
The GPS connector type installed is an FME female in those devices equipped with this interface.
PIN
Internal
External
A.3.6 Configuration Connector
The configuration connector installed is a DB9 female.
PIN
2
3
5
A.4 Technical Specifications
Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN Interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
22
Signal
RF In
Gnd
Signal
RxD (Input)
TxD (Output)
GND
Motorola PowerPC MPC82xx
64 Mbytes in SDRAM
FLASH Memory (16 Mbytes)
EEPROM 2 Kbytes, NVRAM 128 Kbytes
Ethernet (802.3)
4 port switch managed through MDI/MDX autodetection
10/100 Mbps (BaseT)
M12 8P X-Code Female connector
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depending on the wireless WAN
version running in the device.
Depending on the wireless WAN version running in the device. Please refer to the
manual on the relevant module.
Up to 4 coaxial connectors, type N
RF FME Male Connector
DB 9 Female
Teldat S.A.
Teldat H2 RAIL Lite
