Manual
Teldat S.A.
Teldat 4Ge Router
Installation Manual
Copyright© Teldat-DM571-I Version 7.1 4/2016 Teldat S.A.
Teldat 4Ge Router
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4Ge and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teldat 4Ge

Summary of Contents for Teldat 4Ge

  • Page 1 Manual Teldat S.A. Teldat 4Ge Router Installation Manual Copyright© Teldat-DM571-I Version 7.1 4/2016 Teldat S.A. Teldat 4Ge Router...
  • Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.

  • Page 3: Table Of Contents

    Chapter 2 Teldat 4Ge Router ....... . . 4 Characteristics ........
  • Page 4 Radio Information ....... . . 28 RF LTE Specifications ....... . . Teldat 4Ge Router...
  • Page 5 Table of Contents Teldat S.A. RF GSM/WCDMA Specifications ......Teldat 4Ge Router...
  • Page 6 Table of Contents Teldat S.A. Teldat 4Ge Router...

  • Page 7: I Related Documents

    Related Documents Teldat S.A. I Related Documents Teldat-Dm748-I Software Updating Teldat 4Ge Router...

  • Page 8: Chapter 1 About This Guide

    1 About This Guide Teldat S.A. Chapter 1 About This Guide This is the installation guide for the Teldat 4Ge router. It contains information on how to correctly install this device in a working environment. 1.1 Supported Devices The information included in this installation guide only applies to the Teldat 4Ge router.
  • Page 9 1 About This Guide Teldat S.A. Fax: +34 918 076 566 Email: support@teldat.com Teldat 4Ge Router...

  • Page 10: Chapter 2 Teldat 4Ge Router

    2.1.2 Hardware Monitoring The only way to monitor the Teldat 4Ge router hardware is through the LEDs panel. The LEDs provide visual inform- ation on what is happening in the device. These indicate the state of the hardware components, if there is connectiv- ity, data flow, etc.

  • Page 11: Chapter 3 Components And Power Supply

    Front panel elements table Item Description WWAN antenna for the Teldat 4Ge. Slot for the SIM card. 3.1.2 Rear Panel The following figure shows the rear panel. Here you can see all the connectors for the Teldat 4Ge router. Teldat 4Ge Router...

  • Page 12: Side Panels

    Two WWAN antennas are located on the side panels, one on either side. Right hand side panel Left hand side panel Fig. 3: and Fig. 4: 3.1.4 Underside Panel The following elements can be found on the underside panel: Teldat 4Ge Router...

  • Page 13: Top Panel (Leds)

    Perforations to install a DIN rail mount. (Optional) 3.1.5 Top Panel (LEDs) The LEDs panel provides information on the state of the components (whether they are active or not) and on the net- work activity. Leds Panel Fig. 6: Teldat 4Ge Router...

  • Page 14: Assembly

    3 Components and Power Supply Teldat S.A. The LEDs for the Teldat 4Ge router are shown in Figure 6. The table below contains a description of them: LEDs table Status Description Tricolor Green -> connected. Blinking: con- nection data activity Amber ->...
  • Page 15 The screws must go into a wall stud (wood) or a wall anchor of the appropriate type for the wall. Screws into drywall are not strong enough to mount the router. Wall-Mounting Features on the router Fig. 9: The above figure shows the wall-mounting features on the Teldat 4Ge router. Wall screws 8,8 cm (3.46 inches) Chassis mounting holes (on...

  • Page 16: Ceiling Mounting

    - The accessories must be properly adapted to the kind of wall in place and must be chosen to ensure that they can support the weight of the device. 3.2.4 Ceiling mounting To attach the device Teldat 4Ge to the ceiling, use the appropriate support (not included, must be ordered separ- ately). Ceiling mounting support Fig.

  • Page 17: Installing A Din Rail Mount Accessory (Optional)

    DIN rail mount adapter Fig. 11: 3.3 Power Source The Teldat 4Ge router is powered though an external AC/DC source or through an Ethernet cable (if it complies with the POE 802.3af standard). Warning The equipment must be used with the power supply provided by the manufacturer.

  • Page 18: Poe

    Diagram to connect the PoE adapter to the router Fig. 12: The Teldat 4Ge router can be powered through an Ethernet cable if the latter complies with the POE 802.3aF stand- ard. The ETHERNET port is enabled for this. To connect the Ethernet cable with PoE power to the router, please carry out the steps outlined in section...

  • Page 19: Disconnect

    • Router: If you have a router license, the device will behave as a router. In this case, the default configuration estab- lishes the following access IP address and the mask: IP address: 192.168.1.1 IP mask: 255.255.255.0 • 4Ge: If you have a 4Ge license, the device will have a special configuration. Please see manual Teldat-Dm592 - Teldat 4Ge Router...

  • Page 20: Connecting Data

    Cell (located on the front panel of the router). The installation of these antennas in the Teldat 4Ge router is essential in order to improve the quality of the signal received and transmitted by the cellular model.

  • Page 21: Installing The Sim Card

    3.6 Installing the SIM card A SIM card needs to be inserted in the Teldat 4Ge so the WWAN interface operates correctly. The router is equipped with an external tray for SIM cards. When inserting the SIM card, make sure you are protected against electrostatic discharges (ESD).
  • Page 22 Procedure: • Position the router as shown in the figure above. • To insert the SIM card, you must introduce it as shown in the figure on the Teldat 4Ge. • Then press it until it is fully inserted. • To extract it, press it again and remove it.

  • Page 23: Chapter 4 Compliance

    4 Compliance Teldat S.A. Chapter 4 Compliance 4.1 Manufacturer Information Teldat Brand Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton, 10 Parque Tecnológico de Madrid, 28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 Teldat 4Ge Router...

  • Page 24: Safety Warnings

    4 Compliance Teldat S.A. 4.2 Safety Warnings Connect Disconnect Teldat 4Ge Router...
  • Page 25 4 Compliance Teldat S.A. Teldat 4Ge Router...
  • Page 26 4 Compliance Teldat S.A. Teldat 4Ge Router...

  • Page 27: Weee Information

    Directiva 2014/35/UE (LVD) Directiva 2009/125/CE (ErP) Directiva 2011/65/UE (RoHS) del parlamento Europeo Note —Directive 2014/53/EU (RED) replaces Directive 1999/5/EC (R&TTE) on 13th June 2016 The EC declaration of conformity and additional product documentation can be accessed here: http://www.teldat.com Teldat 4Ge Router...

  • Page 28: Ce Marking

    In accordance to article 10 of 2014/53/EU we inform you that there may be national restrictions and requirements for authorization. The requirements for any country may evolve. Teldat S.A. recommends that you check with local au- thorities for the latest status of their national regulations.

  • Page 29: Can Ices-3 (B)/Nmb-3(B)

    This device and its antennas(s) must not be placed or operated in conjunction with any other antenna or transmitter, except when done in accordance with IC multi-transmitter product procedures. Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. Teldat 4Ge Router...

  • Page 30: Appendix A Technical Information

    A.2 Updating the software The Teldat 4Ge router can be updated to new releases. Please contact your distributor for further details on new re- leases. Firmware updating is carried out through a traditional FTP file transfer. For further information on updating firmware through FTP, please see manual Teldat-Dm748-I Software Updating, section 1.3 FTP Updating.

  • Page 31: Lan Connector

    A.3.2 WWAN Connector (female) Internal RF in/out External A.3.3 Power Supply Connector Internal POSITIVE External NEGATIVE A.4 Technical Specifications A.4.1 Hardware Architecture PROCESSORS Freescale P1014 MEMORY DDR3 1Gbit (128 MByte) STORAGE UNIT FLASH Memory 128 Mbits (16 Mbytes) Teldat 4Ge Router...

  • Page 32: Lan Interface

    A.4.5 External Power Supply INPUT VOLTAGE 100-240 V AC INPUT CURRENT 1.0 A INPUT FREQUENCY 50-60 Hz A.4.6 Dimensions and weight TYPE Desktop or wall mounted. LENGTH x WIDTH x HEIGHT 145 x 160 x 50 mm WEIGHT 0.3 kg Teldat 4Ge Router...

  • Page 33: Environmental Specifications

    Technical Information Teldat S.A. A.4.7 Environmental Specifications TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC STORED: -25 ºC to 70 ºC RELATIVE HUMIDITY On: 5 % to 90 % Teldat 4Ge Router...

  • Page 34: Appendix B Radio Information

    The GSM/WCDMA equipment model with the MC8705 module provides WCDMA, GSM, GPRS, EDGE network con- nectivity over several radio frequency bands, in accordance with 3GPP Standards. This product is supplied with antennas YWX-6231SAX9-508. To comply with the regulations, do not choose other antennas. Technology: UMTS(WCDMA) Teldat 4Ge Router...
  • Page 35 Technology: GSM / GPRS / EDGE Bands Frequencies Radiated Transmit Power EGSM 900 (900 MHz) Tx: 880–915 MHz +29 dBm ± 1 dBm Rx: 925–960 MHz DCS 1800 (1800 MHz) Tx: 1710–1785 MHz +27 dBm ± 1 dBm Rx: 1805–1880 MHz Teldat 4Ge Router...
