Procedure J. Power Up (cont'd)
Step
18 In the Cable Delay area: Enter the number of ns corresponding to your cable kit part
number from the list below. Type or use the up and down arrows on the right side of
the data entry box.
Antenna Type
96
TimeSource 2500
S S S S S S S
Cable Kit Part No.
Window 093-71316-04
Wall 093-71317-04
Window 093-71240-10
Wall 093-71241-10
Window 093-71400-15
Wall 093-71401-15
Window 093-71400-20
Wall 093-71401-20
S S S S S S S
Action
Total Cable
Length (ft)
S S S S S S S
Delay (ns)
40 65
100 158
150 242
200 320
