Procedure H. Cable Installation–Maximum 150 Foot or 200 Foot Cable (cont'd)
Step
7 Use weatherproof caulking to seal the opening where the cable exits the building.
8 Attach the other end of the same LMR-240 cable to the adapter installed in Step 2.
9 Connect one end of the LMR-400 cable to the adapter installed in Step 2.
10 Connect the other end of the LMR-400 cable to the adapter installed in Step 4.
11 Attach the N end of the other LMR-240 cable to the other side of the adapter
installed in Step 4.
12 Route the same LMR-240 cable to the rear of where the TimeSource 2500 Shelf will
be installed.
