View Input Performance Statistics

1. Select Precision Sync Monitor.
2. View the accumulation period
for the data, in seconds.
3. View the statistics data, which is
the report of the measurement
difference between the provisioned
inputs and the TimeSource 2500
output.
This data can be plotted and
compared against any one of
several timing performance
masks, to gauge the quality of
the timing being received on the
input(s). Timing performance
mask(s) and spreadsheet
software are not available from
Symmetricom, and must be
obtained from third party
vendors.
4. View the phase data, which is
the phase offset, in ns, for each
input used in the BesTime
calculation.
5. To include statistics data in the
log file, select Statistics.
126
