Figure 9. Antenna-to-Shelf Connection with Cable Kit 093-71317-04
(Attached to cable)
LMR-240 Cable (6 ft)
(Attached to cable)
(Attached to cable)
SMA Connector
(Attached to cable)
32
TimeSource 2500
S S S S S S S
TNC Connector
060-00048-01
N Connector
SMA Connector
TimeSource 2500
090-71000-02
S S S S S S S
Antenna Mounting Bracket
070-00383-01
Antenna
090-71010-89
Cable Mounting Bracket
(Attach to inside wall)
070-00379-02
with N-to-SMA Adapter
(121-00560-01)
RG-316 Cable (40 ft)
060-00062-02
RG-316 Cable Clip(s)
128-00315-01
TNC-to-SMA Adapter
121-00563-01
