Figure 14. Window Antenna-to-Shelf Connection with Cable Kit 093-71240-10
SMA Connector
(Attached to cable)
SMA Connector
(Attached to cable)
TNC Connector
(Attached to cable)
TNC Connector
(Attached to cable)
S
S
S
S
S
S
S
S
TimeSource 2500
090-71000-02
S
S
S
S
S
S
S
S
Antenna
090-71010-87
RG-316 Cable Clip(s)
128-00315-01
RG-316 Cable (10 ft)
060-00062-01
Mounting Bracket
(attach to wall adjacent to window)
070-00379-01
with TNC-to-SMA Adapter
121-00562-01
LMR-240 Cable (100 ft)
060-00063-01
S
S
S
S
S
S
S
S
51
Installation
S
3
3
4
5
