Download New Software (cont'd)
4. Verify the file name is correct.
5. Verify the baud rate is set to
19200. Do not use any other baud
rate.
6. To continue the downloading
process, click Continue. To cancel
the downloading process (if
desired), click Cancel.
A progress bar and messages
track the download process.
7. Once the download is
complete, a message appears. Click
OK.
8. The TimeSource 2500 breaks,
then reestablishes, communication
with the host computer, and a
message appears. Click OK.
9. To exit the application, click Exit
when the BTMONitor main screen
appears.
10. To use the upgraded software,
restart BTMONitor. (Double-click
the BTMONitor icon on the
desktop.)
