Wall Antenna Installation

Procedure E. Wall Antenna Mounting
Step
1
Use Figure 17 to determine the spacing of the hole for the antenna cable, and the
holes for the customer-supplied screws or bolts, which will be used to mount the
antenna bracket assembly to the outside wall.
2 Drill a hole in the wall for the antenna cable. The diameter of the hole should be
slightly larger than the outer diameter of the TNC connector, which will connect to
the antenna connector.
3 Drill two pilot holes for the screws or bolts.
4 Remove the antenna from the mounting bracket (remove the plastic cap, nut, and
washer, then remove the antenna).
5 Assemble the antenna and mounting bracket as follows:
a. Slide the gasket, bracket, then washer, over the antenna connector, and position
against the antenna.
b. Screw the nut over the antenna connector, onto the assembly.
6 Using two screws or bolts, mount the antenna bracket assembly to the outside wall.
56
TimeSource 2500
S S S S S S S
For TimeSource 2500 Systems with wall antennas, use this
section. For TimeSource 2500 Systems with window antennas, use
the "Window Antenna Installation" section.

Antenna Mounting

To mount the antenna through the wall, refer to Figures 17
and 18, and follow Procedure E.
S S S S S S S
Action
