Procedure I. Rack Mounting
Step
1
Position the mounting ears on the shelf for flush mounting or 5 in. offset mounting, as
required. If mounting in a 23 in. rack, attach the 23 in. rack adapters.
2
Mount the shelf in the rack.
3
If a wire-wrap panel is not used, this procedure is completed. If using a wire-wrap
panel, mount the panel (Figure 24) to the rack just below the TimeSource 2500.
4
Connect the cables (included in the wire-wrap panel kit) between the front panel
connectors of the TimeSource 2500 and the connectors on the inside of the wire-
wrap panel, as listed in Table C.
68
TimeSource 2500
