Antenna

Installation procedures are to follow local company procedures
and the Installation Job Specification.

Window Antenna Installation

For TimeSource 2500 Systems with window antennas, use this
section, and skip the "Wall Antenna Installation" section. For
TimeSource 2500 Systems with through-the-wall antennas, skip
this section, and use the "Wall Antenna Installation" section.

Antenna Mounting

To mount the antenna on the selected window (inside the
building), follow Procedure A.
Procedure A. Window Antenna Mounting
Step
1
Pull the Velcro brand hook-and-loop strips (located on one side of the antenna)
apart.
2 On the strip that is not attached to the antenna, remove the tape from the strip.
3 Apply the sticky side of the strip to the center of the window, inside the building.
Press firmly to remove any air pockets from between the strip and the window.
The antenna must be oriented with the writing on the antenna box facing towards
you. Do not rotate the antenna so that the writing is vertical or upside down.
4 Press the strip attached to the antenna to the strip attached to the window.
