INSTALLATION
Separate the two keypad halves by carefully inserting a small screwdriver into the release slots on the bottom edge
of the keypad front half and applying a gentle pressure. This will release the bottom edge of the housing enough for
you to unclip the top.
Screw the base to the wall using the mounting holes provided. These holes will match the standard single switch
plate spacing. Ensure the base is mounted right side up. It is marked with the word "TOP" to aid orientation. When
fixing the base to the wall make sure the top of the screw heads will not touch or short out the underside of the PCB
when the top half of the keypad is reinstalled. Bring the cables through the centre of the base.
Connect the 4 or 5 wires to the 5 way terminal block on the rear of the keypad PCB making sure to match the
cables up with the terminals as marked on the control panel's keypad port. The 5th wire is connected from the "LIN"
terminal of the keypad to the "Listen" terminal of the Elite PCB keypad port.
Once the cables have been terminated and the required address allocated (see section below) clip the front half of
the keypad onto the base by first engaging the clips at the top edge and then close the front down and clip it in at
the bottom. Now stick the zone list provided to the inside of the hinged lid.
WIRING
The Elite keypad connects to the Elite Controller via a 4 or 5 wire data & power connection. A maximum of 8 LED
keypads can be connected, each wired in parallel. A 5th wire may be used to provide a "Listen-in" facility at the
keypad when an Elite communicator panel is being used.
The maximum recommended cable using standard 0.2mm security cable is 50m. Cable runs exceeding this
distance may require 0.5mm cable. Always use good quality cable. Some installations may require data cable to
ensure data integrity in noisy sites.
Keypad
Address
# A
1
X
2
3
X
4
5
X
6
7
X
8
X denotes link is cut
Address
Links
B C
X
X
X
X
X X
X X
Each of the 8 possible LED keypads which are able to be
connected to your Elite panel must be addressed individually to
avoid BUS conflicts and other communication problems. As
default, each keypad comes addressed as #1 with all links
intact.
Use the table to the left to determine which links to cut to assign
the correct address to the keypads you are installing.
eg. To assign a keypad as address #2, you must cut link A
only. To assign a keypad as address # 4, you must cut link
A&B.
When cutting address links it is important to make a clean cut
between the link blocks as shown below. Links can be restored
A B
Page 15
C
cut here
