TO EXIT PROGRAM MODES

To exit program modes when you have finished programming:
The panel is now back in Run Mode, any program changes you have made will have replaced previous values and
be in effect.
Note: During programming Tampers and 24 hour alarms are disabled which allows quiet access to the panel,
detectors and satellite siren units etc. On exiting program mode, all inputs are scanned and if any tampers or 24Hr
alarms are present an activation will occur.
Note: Where there are multiple options at one address, options 0 & 9 have been reserved. Entering a 0 at
USER CODES - (P1E to P24E) & (P99E)
There are 25 codes available in the Elite, 24 user codes and 1 install code. The user codes are located in
addresses 1-24. As default, Code 1 has Master Code permissions and must be used to enter program mode. The
Installer code is stored at address 99 and is used to move from Client Program mode up to Installer Program mode.
Codes 1-24 may be varied in length from 1 to 6 digits.Code 99 must be 3-6 digits.
To program a User Code you must first be in client or installer program mode, then select the address from 1-24. (If
there is already a code programmed at this address, it will be flashed back to you) Now enter the code then press
the ENTER key.
In this example we have set Code 1 ( Master Code ) to be 1234.
In this example we have set code 5 to be 567
To replace a code simply enter the new code in the same address as the old code. This will overwrite the previous
code but maintain the user permissions as mapped to that user number.
To clear or delete a code simply enter the EXCLUDE button at the address where the old code is stored.
When flashing back codes and values Zone indicators 1-8 are used to indicate digits 1-8. The digit 0 is indicated by
the "A" light and 9 is indicated by the "B" light.
Press <PROGRAM> - <ENTER>
Program light goes out
eg. P 1 E 1234 E
3 beeps - program light flashing
eg. P 5 E 567 E
3 beeps - program light flashing
eg. P 3 E <EXCLUDE> E
3 beeps - Program light flashing
Page 18
