SOFTWARE CHANGES TO ELITE 16D

There have been a number of improvents to the latest version of panel software (V4.20) which differ from previous
versions of software V4.16 and below. These are;
1) The PWM or siren driver option for outputs 1 & 2 have now moved from P201E options 1 & 2 to P101E and
P102E option 8.
This is an important change as connecting a horn speaker to output 1 & 2 without first making the output a PWM
siren output could cause damage to the panel.
2) The auto arming time zone for a partition P170E, P270E & P370E is now an auto-arming and/or auto-disarming
time zone.
Having selected a suitable time at the above address the desired option of auto-arming, auto-disarming or both is
selected at addresses P180E, P280E, P380E option 1 & 2.
3) The output pulse timer is now programmable in 1/10 second increments instead of 1 second increments. The
radio chirps to an output are now linked to the pulse timer for that output eg if the pulse timer has a value of 1
programmed then the chirp duration will be 1/10 second on then 1/10 second off,etc.
If you require the chirps to be longer in duration eg to allow a satellite board to provide the chirps, then you must
make the pulse timer value larger. Typically a value of 3 or 4 for the pulse timer will give the same length of chirp
pulses that earlier software versions provided.
4) Programming of daylight saving has changed to fit in with the international standard for setting daylight saving.
Refer to the manual for more details.
5) Previously if you did not require an exit delay for monitor mode you programmed this option at addresses P198E,
P298E and P398E option 1. This option has moved and been expanded.
At P180E, P280E and P380E options 3,4,5 and 6 you can now select no entry or exit delay for monitor mode or full
set.
6) If a day zone is programmed to operate an output, the duration of the output on time is now linked to the day
zone to keypad buzzer timer (P457E, P458E and P459E).
The day zone output can also be made to pulse the output at a rate equivalent to the pulse timer setting for that
output at addresses P101E to P108E option 7.

ADDITIONAL FEATURES NOW AVAILABLE WITH V4.20

1) Upload/download is now available via a dial up link or by direct connection of a PC via the serial port.
2) The zone response time is now adjustable from 1 - 32 (default = 6). The program address is P709E.
3) The panel has a time and date stamped 63 event buffer which can be sent to a serial printer via the serial port.
4) A back-up of the panel programmed data can be made to an Eeprom board via the serial port. This allows re-
instatement of the panel program at a later date (refer P736E and P738E).
5) A zone reporting delay P450E has now been included which delays the reporting of zone alarms via the dialler
(default = no delay).
6) A fax defeat option is now included for the auto-answer feature in dialler panels (refer P260E)
7) 24hr alarms can now be programmed to send an alarm in voice or domestic reporting modes (refer P322E,
P324E and P326E).
Page 78
