PARTITION "A" SPECIFIC OUTPUT OPTIONS second set - P181E - P188E
As with P171E to P178E, this block of addresses sets a number of output options which are specific and unique to
the operation of partition or Area "A". Activity in Areas "B" or "C" will have NO direct effect on the options set at
these addresses.
P181E 1E Any exclude to output #1
2E Auto-Exclude warning to output #1
3E Entry beeps to output #1
4E Exit beeps to output #1
5E Control function to output #1
6E Set/Unset indication to output #1
7E Monitor Mode on/off to output #1
8E Keypad Duress to output #1
Option 1 Any exclude to output #1 - This option will produce a change of state at output #1 if there are any
zones excluded, either manually or automatically. This change of state will occur at the end of the Exit
delay. The output reset time (P421E) should be set to zero when this option is enabled.
Option 2 Auto-Exclude warning to output #1 - This option will produce a 2 second pulse at output #1 at the
end of the exit period if a zone has been Auto-excluded in Area "A". An Auto-Exclude occurs when a
zone is left un-sealed at the end of the exit delay. At the end of the exit delay zones not defined as
Auto-Exclude which are left un-sealed will produce an activation. Auto-Exclude assignments are found
at P342E and P362E
Option 3 Entry beeps to output #1 - This option will map the keypad entry beeps to output #1.
Option 4 Exit beeps to output #1 - This option will map the keypad exit beeps to output #1.
Option 5 Control function to output #1 - This option maps the control functions in Area "A" to output #1.
Control function parameters for Area "A" are defined at P198E options 5-8
Option 6 Set / Unset indication to output #1 - This option will turn output #1 on when Area "A" is armed and
turn output #1 off when Area "A" is disarmed. This change of state occurs at the start of the exit delay
and when the Area is disarmed. Output reset time should be set to zero (P421E0E)
Option 7 Monitor Mode on / off - This option will turn output #1 on when Area "A" is placed in Monitor Mode
and turn output #1 off when Area "A" Monitor Mode is turned off. Like option 6 this change of state
occurs either at the start of the exit delay or when the Area is disarmed. Output reset time should be
set to zero (P421E0E)
Option 8 Keypad Duress to output #1 - This option will produce a change of state at output #1 when a Duress
Alarm is activated. A Duress Alarm is activated only when the pre-defined "Duress Digit" (P197E) is
prefixed to a valid Area "A" user code and entered at an Area "A" keypad. Output reset time should be
set to zero (P421E0E)
* * NOTE: The Duress Alarm can only reset by arming then disarming the affected area * *
Note: P182E through P188E are as above but applied to outputs 2-8
PARTITION A KEYPAD OPTIONS - P189E & P190E
P189E "ARM" key can disarm during exit delay - This option enables the one key disarm during exit delay
feature on a keypad by keypad basis with Partition boundaries . Options 1-8 represent keypads 1-8
P190E "MONITOR" key can disarm during Monitor Mode - This options enables single button disarm of the
monitor mode via the "MONITOR" key. Options 1-8 represent keypads 1-8
Page 25
