MISCELLANEOUS OPTIONS - P201E to P206E
P201E 1E Mains input AC or DC
2E Ignore Mains input
3E Low Keyswitch is momentary or latching
4E High Keyswitch is momentary or latching
5E Cabinet tamper is loop or end-of-line
6E Installer lockout
7E Area "C" is zones shared with Area "A" & "B", i.e. Area "C" is zones common to "A" & "B"
8E Local serial port speed
Option 1 Mains input is AC or DC - The AC input on the panel can be 17vac @ 50hz or a DC input
between 16-30v DC.This option stops the Mains fail from occurring if a DC input is applied.
Option 2 Ignore Mains Input - If the panel must be run off a 12v DC supply only such as a solar
application the the 12v can be applied to the battery input and the mains input is ignored.
Option 3 Low Keyswitch is momentary or latching - This option determines if the low Keyswitch (4k7)
is momentary or latching. If option 3 is on the low Keyswitch will be momentary (Default)
Option 4 High Keyswitch is momentary or latching - This option determines if the high Keyswitch (8k2)
is momentary or latching. If option 4 is on the high Keyswitch will be momentary (Default)
Option 5 Cabinet tamper is loop or end-of-line - This option determines if the Cabinet tamper input
uses a closed loop or 2k2 end-of-line resistor. If option 5 is on the tamper is a 2k2. (Default)
Option 6 Installer lockout - If this option is enabled, the installer "Back Door" power up access to
program mode will be disabled. (Default off)
Option 7 Area "C" is zones shared with Areas "A" & "B" - If the system uses zones which are common
to Area "A" and Area "B" then Area "C" is used for those shared zones. If zones are not shared
between A & B then Area "C" is available as a independent partition. Light on = Shared
Option 8 Local serial port speed - This option sets the local communications speed of the local RS232
port to be 9600bps. If this option is off the com port speed is set to 2400bps.
P204E 1-255E Spare
P205E 0-255E Spare
P206E 1-255E Spare
Page 29
