Intek Elite 16D Installation & Programming Manual page 23

The block of addresses from P140E to P158E are used to assign the basic function options of each keypad in the
system. Each of the address lines from P140E to P158E may have 8 options assigned where the 8 options
represent the individual addresses of the keypads in the system. i.e. if options 1, 2 & 4 are enabled at address
P140E then keypads 1, 2 and 4 would be assigned to area "A".
P140E 1-8E Keypads assigned to Area A (Default 1-8)
P141E 1-8E Keypads assigned to Area B (Default none)
P142E 1-8E Keypads assigned to Area C (Default none)
P143E 1-8E Keypads with permission to Set (Default 1-8)
P144E 1-8E Keypads with permission to Monitor (Default 1-8)
P145E 1-8E Keypads with permission to use the Control Function (Default 1-8)
P146E 1-8E Keypads with permission to Exclude (Default 1-8)
P147E 1-8E Keypads with permission to Line Monitor (Default 1-8)
P148E 1-8E Keypads with permission to program User Codes (Default 1-8)
P149E 1-8E Keypads with permission to Installer Program Mode (Default 1-8)
P152E 1-8E Keypads with facility to turn the LED's off after Exit Delay (Default none)
P153E 1-8E Keypads with buzzer mapped to keypad tampers (Default 1-8)
P154E 1-8E Keypads with buzzer mapped to zone tampers (Default 1-8)
P155E 1-8E Keypads with buzzer mapped to system tampers (Default 1-8)
P156E 1-8E Keypads with Panic button enabled (Default 1-8)
P157E 1-8E Keypads with buzzer mapped to keypad panic activation (Default 1-8)
P158E 1-8E Keypads with buzzer mapped to phone line failure (Default none)
At address lines such as P140E where there are 8 bits or options available, each option can be selected by
pressing the numeric key which corresponds to the option or bit number your wish to enable.
For example, to assign keypads 1,2, & 4 to Area "B"
When you enter the program address, i.e. P140E, any existing options will be displayed to you. As you enter your
options, the display will be updated to show the current option status.
NOTE: If an option is already enabled pressing the numeric key which corresponds to that option will
toggle the option off.
Note: Where there are multiple options at one address, options 0 & 9 have been reserved Entering a 0 at
P 141 E 124 E
LED's 1,2 & 4 come on
3 beeps, program light flashing
Page 23
