ENROLLING RADIO KEYS - P541E - P556E
In the Elite 16D we refer to wireless pendant transmitters as "Radio Keys". Because the Elite recognises each
button as a separate function or user we refer to each button or user separately in that if you are loading a three
button radio key, you would actually be enroling 3 separate radio users. It is possible to enrol several radio users
as one where you are able to program the transmitter code of the radio key (usually via dip switches) to key them
alike. Where you can not program the transmitter code of the radio keys you must enrol them as separate users.
Radio users are enrolled in the same way as Radio Detectors. Press the program key then the address then the
ENTER key then trigger the radio Key with the button you wish to load at that address.
P541E Enrol Radio user # 1
P542E Enrol Radio user # 2
P543E Enrol Radio user # 3
P544E Enrol Radio user # 4
P545E Enrol Radio user # 5
P546E Enrol Radio user # 6
P547E Enrol Radio user # 7
P548E Enrol Radio user # 8
P549E Enrol Radio user # 9
P550E Enrol Radio user # 10
P551E Enrol Radio user # 11
P552E Enrol Radio user # 12
P553E Enrol Radio user # 13
P554E Enrol Radio user # 14
P555E Enrol Radio user # 15
P556E Enrol Radio user # 16
RADIO KEY OPTIONS 1st Set - P561E - P576E
In the same way that permissions are set for user codes, Radio Keys are also assigned permissions which
determine their functionality.
P561E 1E Radio user #1 has Area "A" permissions (Default all)
2E Radio user #1 has Area "B" permissions
3E Radio user #1 has Area "C" permissions
4E Radio user #1 will arm
5E Radio user #1 will disarm
6E Radio user #1 will turn Monitor Mode on
7E Radio user #1 will turn Monitor Mode off
8E Radio user #1 is disabled during alarm state
Option 1 Radio user #1 has Area "A" permissions - The functions set by options 4-7 will be active in
Area "A"
Option 2 Radio user #1 has Area "B" permissions - The functions set by options 4-7 will be active in
Area "B"
Option 3 Radio user #1 has Area "C" permissions - The functions set by options 4-7 will be active in
Area "C"
Option 4 Radio user #1 will arm - When this option is enabled, radio user #1 will arm which ever area is
assigned by options 1-3
Page 35
