ARMING THE PANEL

PRESS <ARM>
OR <CODE> <ENTER>
OR <ARM> <CODE> <ENTER>
The mode for arming above depends upon the programmed panel operation. Also, the arming mode can vary from
one keypad to another, depending upon how the system is programmed.
If the arm sequence was successful, the relevant armed LED will turn on (ARMED, A or B) or a combination of
these, depending upon the areas assigned to a particular user code.

DISARMING THE PANEL

PRESS <CODE> <ENTER>
If the disarm sequence was successful, the relevant armed LED (ARMED, A or B) will turn off depending upon the
area/s assigned to a particular user code.

EXCLUDING ZONES

FIRST ARM THE ALARM AS ABOVE
DURING THE EXIT DELAY PRESS <EXCLUDE>
(The exclude LED will turn ON).
Next; Select any zone/s from 1-8 that you wish to exclude by pressing numbers 1-8 on the keypad. The appropriate
green zone led will turn on to show that the zone/s will be excluded.
To exclude zones 9-16 (if the panel is set up as a 16 zone panel);
PRESS <EXCLUDE> again.
The "Aux." led should be ON. Now numbers 1-8 (and zone leds 1-8) will select 9-16 (eg 1=9 - 8=16)
Once all the zones you wish to exclude have been selected;
PRESS <ENTER>.
This will then start the full exit delay timer and you should exit the building.
MONITOR MODE ARMING
PRESS <MONITOR>
OR <MONITOR> <CODE> <ENTER>
Above choice depends upon programmed options.
The relevant monitor led (either ARMED, A or B) will flash to indicate that monitor mode is on.
MONITOR MODE DISARMING
PRESS <CODE> <ENTER>
Monitor mode led (ARMED, A or B) will turn OFF.
If the keypad is programmed for one button monitor mode disarming then simply pressing the <MONITOR> button
will disarm monitor mode.
CONTROL OPERATION
(CODE = A VALID 1-6 DIGIT USER CODE)
