The Elite LED Keypad consists of; an 18 button, backlit silicone rubber keypad, 20 LED indicators and an internal
piezo buzzer housed in a modern white plastic housing. The plastic housing has a hinged front lid to cover and
protect the rubber buttons when not in use. All the electronics are contained on a single circuit board inside the
housing.
Because the keypads communicate with the controller using data, the cable run from panel to keypads is secure
against tampering. For this reason there is no tamper switch on the keypad assembly. Access to the keypad
electronics will not disarm the panel.

BUTTONS

The 18 silicone rubber buttons are used for the following functions.
In normal operating mode the numeric keys are used for entering Access Codes. In Program Mode the numeric
keys are used for entering options & new values.
The buttons with text labels are used as function buttons and select the options indicated by the text and normally
precede other button presses, e.g. to enter Exclude Mode during the exit delay press <EXCLUDE> and the numeric
key corresponding to the zone number you wish to be excluded.
The PROGRAM Key is used to prefix option selections in the program modes e.g.<PROGRAM> 24 <ENTER>
selects User Code 24. The PROGRAM key is also used prior to a Master Code to enter user program mode from
normal operating mode.
The ENTER Key is used to enter access or program codes. It is normally used at the end of a button sequence
except when it is used in a 16 zone system where pressing the <ENTER> key will toggle the LED display between
the low and high zones. This toggle enables the 8 zone LED's to indicate the status of zones 1-8 (low zones) and
zones 9-16 (high zones). This dual status display is achieved by using the AUX. light to indicate which set of zones
are currently being displayed. i.e. AUX. off = low zones (1-8) or AUX. on = high zones (9-16). The AUX. light flashing
when viewing the low zones means there is a violated zone in the high group.
The CONTROL button, if enabled, is used to produce an output without an alarm event. This control output can be
used to operate other external devices such as garage door openers, door locks, lights or other options as required.

LED INDICATORS

The LED indicators are used to display system conditions including Zone status, Battery state, Tamper etc. Please
refer to the LED table on page 11 for a full explanation of the conditional displays.
A wrong code or Keypad Tamper alarm is generated by the Elite after 4 consecutive invalid code entries. The
controller will not "Lock-Out" the keypad at this point but simply create an alarm condition as determined but the
tamper alarm options (P111E-P118E etc). If the alarm system is a monitored installation, the Elite communicator will
report a keypad tamper to the monitoring company. Entry of a valid user code will reset the Keypad Tamper alarm
however, the alarm event will be written into memory and the keypad memory light will be flashing indicating the
presence of a new memory entry.
Page 12
