PARTITION "A" MISCELLANEOUS KEYPAD OPTIONS - P198E
P198E 1E Spare
2E Arm key required before code to set
3E Monitor key required before code to turn on Monitor Mode
4E Code required to arm area
5E Control function requires code
6E Control function toggles
7E Control function is momentary
8E Control shunts "Day" mode
Option 1 Spare
Option 2 Arm key required before code to set - This option determines if the "ARM" key must be pressed
before a code is entered to set Area "A". This option must be enabled where a keypad is assigned to
more than one area.
Option 3 Monitor key required before code to turn on Monitor Mode - This option determines if the
"MONITOR" key must be pressed before a code is entered to turn on Monitor Mode in Area "A". This
option must be enabled where a keypad is assigned to more than one area.
Option 4 Code required to arm area - If this option is off the partition can be shortcut armed. Shortcut arming
is when the area can be set by pressing the "ARM" key only, i.e. no code is required. If this option is
on, a valid Area "A" user code is required to set the area.
Option 5 Control function requires code - This option determines if a code is required to operate the Control
function. The Control function provides the ability to operate an output from a key press rather than
from an alarm event. If this option is off, pressing the "CONTROL" key will produce an output as
assigned at P181E through P188E option 5
Option 6 Control function toggles - If this function is enabled, the output which is mapped to the control
function will toggle to the opposite state each time the control function is operated, i.e. if the output is
on it will turn off etc.
If the reset time mapped to the control output is zero the output will remain on until the control function
operates again and toggles it off. If there is a reset time mapped to the control output, the output will
turn off at the end of the reset time as expected. The next time the Control function is operated the
output will come on again for the reset period then turn off.
Option 7 Control function is momentary - If this option is enabled, the output which is mapped to the control
function will turn on for the time period as determined by the value of the pulse timer mapped to the
control output.
Option 8 Control shunts "Day" mode - If this option is enabled, pressing the CONTROL button will shunt or
override any Day mode activations. When the Control shunt is active the CONTROL light will be on.
To restore the day function simply press the Control button again.
Note: We advise that only one of the Control Function options be assigned at this address.
