PROGRAMMING DAYLIGHT SAVING ADJUSTMENTS - P712E - P717E
Given that your Elite 16D controller has a real time clock compliant with minutes & hours of the day, days of the
week and months of the year, it is only reasonable to assume automatic adjustments for daylight saving. This block
of addresses provides the Elite 16D with the information required to perform the daylight saving adjustments as
required.
P712E 0-5E Daylight Saving Start Sunday - This is the Sunday number in the month that daylight saving
will begin (values of 1-5 are allowed).
P713E 0-12E Daylight Saving Start Month - This is month in which the above Sunday will occur.(Values of
1-12 are allowed)
P714E 0-24E Daylight Saving Start Hour - This is the hour that daylight savings will begin (values of 0-24
are allowed).
P715E 0-5E Daylight Saving End Sunday - This is the Sunday number in the month that daylight savings
will end (values of 1-5 are allowed).
P716E 0-12E Daylight Saving End Month - This is the month in which the Sunday number will occur (values
of 1-12 are allowed).
P717E 0-24E Daylight Saving End Hour - This is the hour that daylight savings will end (values of 0-24 are
allowed.
P709E Zone Response Time Setting - 1-32E. Default = 6
The input response count sets the total time the zones must be in alarm before the state is recognised by the panel.
A count of 1 = 45ms. The default setting of 6 therefore results in a zone response time of 270ms.
DYNAM IC DAT A
P720E - P725E
The addresses in the block are used to provide real time feedback from the panel as to the current status. These
are intended as view only addresses and only available in installer program mode.
P720E Time Zones active at this time - This address displays the time zones which are currently
active in the system.
P721E Misc System Flags - This address shows the status of up to 8 system operating parameters as
follows
-
1 -7 = Spare
8 = Daylight Saving active
Page 38
