SETTING THE REAL TIME CLOCK - P730E - P734E
This block of addresses is used to set the internal real time clock used by the time zone functions.
P730E 1-7E
P731E 0000 - 2359E
P732E 1-31E
P733E 1-12E
P734E 0-99
P736E W r i t e
to Eeprom Board - with the optional Eeprom back-up board plugged into the serial connector
on the panel and the write enable link on (on the Eeprom board) entering P736E will write a
copy of the panel program files to the Eeprom board.
P738E Read from Eeprom Board - this address allows a copy of a panel program files to be
downloaded into a panel (note the program files must first have been copied to the Eeprom
board - refer P736E)
P740E 1-8E D E -
mapping Outputs 1-8 - This powerful option is used to DE-map or un-assign outputs from all
zone and system functions. This is a particularly useful tool when reassigning outputs to special
functions such as smoke detector reset etc. In addition to removing all programmed links this
option will also remove the reset time and reset the output as a latch.
SET TO DEFAULTS - P741E - P745E
This block of addresses is used to reset sections of the programming back to defaults. Defaults are the values set
when the panel was sent from the factory.
programming. To reset
the entire configuration it
would be necessary to
call each of the
addresses in turn.
P741E Reset user codes
P742E Reset communicator parameters
P743E Reset Radio parameters
P744E Reset all other parameters
Set day of the week - where values of 1-7 represent Sunday to Saturday (Sunday = 1)
Set time - Use 24 hour format
Set day of the month - where values of 1-31 represent days in the month.
Set Month
Set Year - Where 0-99 represent years, i.e. 97 = 1997. The Elite 16D is fully 2000
compliant so values of 00 or higher will represent the year 2000 etc.
Each of the addresses in this block defaults one part of the
Page 40
