OUTPUT AUTO ON/OFF TIME ZONES - P121E - 128E
This block of addresses are used to map automatic turn on and turn off periods to each of the outputs where
required. The start of the time zone will cause outputs mapped at these addresses to turn on whereas the end of
the time zone will cause the output to turn off. As with User Code time zones, the actual times assigned to each
time zone(1-8) are defined at addresses P801E - P824E. Multiple Time Zones may be assigned to each output
P121E TZE Where TZ represents the Time Zone # which defines the turn on and turn off times required for
output #1
P122E TZE Where TZ represents the time zone # which defines the turn on and turn off times required for
output #2
P123E TZE Where TZ represents the Time Zone # which defines the turn on and turn off times required for
output #3
P124E - P128E As per above but for outputs 4-8
NOTE: A value of zero (0) at these addresses will disable any auto turn on turn off features at that output.
OUTPUT ENABLE TIME ZONES - P131E - P138E
This block of addresses are used to map enable time zones to each of the outputs as required. The assigned time
zone will enable the output to be activated. As with User Code time zones, the actual times assigned to each time
zone(1-8) are defined at addresses P801E - P824E. This feature is normally used to restrict the Access Control
functions to pre-determined times and days
P131E TZE Where TZ represents the time zone which enables output #1
P132E TZE Where TZ represents the time zone which enables output #2
P133E TZE Where TZ represents the time zone which enables output #3
P134E - P138E As per above but for outputs 4-8
NOTE: A value of zero (0) at these addresses will enable that output 24hrs 7 days.
KEYPAD OPTIONS - P140E - P158E
All keypads must be assigned to a partition or area. Keypads may be assigned in more that one area whereby the
area setting and unsetting is determined by the user code permissions. If a keypad is assigned to one area only,
activity in another area will not be shown. (with the exception of zone indications).
NOTE: A keypad can only be used to control the partition or area to which it has been assigned.
Within the display of the Elite V4 keypads you will find an "ARMED" indicator as well as area "A" and area "B"
indicators. When a keypad is assigned to only one area, the "ARMED" indicator will show steady on for armed,
flashing on and off for monitor and steady off for disarmed.
If a keypad is assigned to multiple areas the area "A" and "B" indicators will show steady for area armed, flash on
and off for area in monitor and remain off for area disarmed. Area "C" is indicated by the "ARMED" light in the
same way as the "A" and "B"
NOTE: In a partitioned system areas A, B & C can be set, unset and monitored independently
