1.6

Specifications

Specifications
Ethernet I/F
Protocol
RFID Card Protocol
Power Input
Speaker Output
On-Board Relay
Supported RFID cards
Enrollment Encryption Level
Payload Types
Video Codec
Camera Resolution
SIP Video Payload
Video Lens Angle
Network Security
IP Rating
Operating Range
Storage Temperature
Storage Altitude
IP Rating
b
Dimensions
Weight
Boxed Weight
Compliance
Warranty
Part Number
a. Contacts 1 and 2 on the terminal block are only for powering the device from a non-PoE 12VDC power source as
an alternative to Network PoE power. Use of these contacts for any other purpose will damage the device and void the
product warranty.
b. Dimensions are measured from the perspective of the product being upright with the front of the product facing you.
Operations Guide
Table 1-1. Specifications
10/100 Mbps
SIP RFC 3261 Compatible
ISO/IEC 14443 Type A - 13.56 MHz Standard
PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply
2 Watts Peak Power
1A @ 30 VDC
Mifare Plus X 2K or 4K
Encrypted to AES 128
G.711 a-law, G.711 µ-law, G.722, and G.729
H.264 Baseline
320 x 240
Baseline profile @ 320x240
72 degrees
TLS/SSL 1.2
IP65
o o
Temperature: -40 C to 55
Humidity: 5-95%, non-condensing
o o o
-40 C to 70 C (-40 F to 158
Up to 15,000 ft. (4573 m)
IP65
7.480 inch [190 mm] Length
2.284 inch [58 mm] Width
5.118 inch [130 mm] Height
2.8 lbs. [1.27 kg]
4.0 lbs. [1.81 kg]
CE; EMC Directive – Class A EN 55032 & EN 55024, LV Safety Directive – EN 60950-1, RoHS
Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class A, IEEE 802.3 Compliant
2 Years Limited
011478
931667A
o o
C (-40 F to 131 F)
o
F)
Product Overview
Specifications
a
(not included)
