1.6

Specifications

Specification
Ethernet I/F
Protocol
Power Input
Speaker Output
On-Board Relay
Operating Range
Storage Temperature
Storage Altitude
IP Rating
Network Security
Payload Types
b
Dimensions
Weight
Boxed Weight
Compliance
Part Number
a. Contacts 1 and 2 on the terminal block are only for powering the device from a non-PoE 12VDC power
source as an alternative to Network PoE power. Use of these contacts for any other purpose will damage
the device and void the product warranty.
b. Dimensions are measured from the perspective of the product being upright with the front of the product
facing you.
Operations Guide
Table 1-1. Specifications
10/100 Mbps
SIP RFC 3261 Compatible
PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply
2 Watts Peak Power
1A at 30 VDC
o o
Temperature: -40 C to 55
Humidity: 5-95%, non-condensing
o o o
-40 C to 70 C (-40 F to 158
Up to 15,000 ft. (4573 m)
IP65
TLS/SSL 1.2
G711, A-law and µ-law, G.722, G.729
7.480 in. [190 mm] Length
2.284 in. [58 mm] Width
5.118 in. [130 mm] Height
2.8 lbs. [1.27 kg]
4.0 lbs. [1.81 kg]
Weather Shroud is 1.2 lbs. [0.54 kg]
CE; EMC Directive – Class A EN 55032 & EN 55024, LV Safety Directive – EN
60950-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class
A, IEEE 802.3 Compliant
011214
011215 Weather Shroud (sold separately)
931562B
o o
C (-40 F to 131 F)
o
F)
Product Overview
Specifications
a
