35. Firewall
Zone
Synopsis: A string
A pre-defined zone
Interface
Synopsis: A string
A pre-defined interface to which optional IPs and/or networks can be added
IP Address List
Synopsis: string
(Optional) Additional IP addresses or networks - comma separated
Figure 35.15. Host Options form
IPsec zone
Synopsis: boolean
Default: false

35.5.6. Policies

Figure 35.16. Main Policy Settings table
Figure 35.17. Main Policy Settings form
Default actions for connection establishment between different zones. Configuration of the default
actions for traffic between different firewall zones. They can be overridden for particular hosts or types
of traffic by defining specific rules.
Policy Name
Synopsis: string
Enter a name tag for this policy
Policy
Synopsis: string - one of the following keywords { continue, reject, drop, accept }
ROX™ v2.2 User Guide 383 RuggedBackbone™ RX5000
