35. Firewall
5. If your network interface IP is dynamically assigned, configure masquerading.
6. If your network interface IP is statically assigned, configure Source Network address Translation
(SNAT). If a sufficient number of IP addresses are provided by the ISP, static NAT can be employed
instead.
7. If your hosts must accept sessions from the Internet, configure the rules file to support Destination
Network address Translation (DNAT). Which hosts need to accept connections, from whom and
on which ports?
8. Configure the rules file to override the default policies. Have external connections been limited to
approved IP address ranges. Have all but the required protocols been blocked?
9. If you are supporting a VPN, add additional rules.
10. Validate the configuration using the method outlined in
Configurations".
11. Activate the firewall. It is recommended to run a port scan of the firewall after activation and verify
that any defined logging is functioning as expected.

35.3. Firewall Terminology And Concepts

This section provides background on various firewall terms and concepts. References are made to the
section where configuration applies.

35.3.1. Zones

A network zone is a collection of interfaces, for which forwarding decisions are made, for example:
Name
net
loc
dmz
fw
vpn1
vpn2
Table 35.2. Network Zones
New zones may be defined at any time. For example, if all of your Ethernet interfaces are part of the
local network zone, disallowing traffic from the Internet zone to the local zone will disallow it to all
Ethernet interfaces. If you wanted some interfaces (but not others) to access the Internet, you could
create another zone.

35.3.2. Interfaces

ROX™ Firewall interfaces are simply the LAN and WAN interfaces available to the router. You must
place each interface into a network zone.
If an interface supports more than one subnet, place the interface in zone 'Any' and use the zone hosts
setup (see below) to define a zone for each subnet on the interface.
An example follows:
Interface
switch.0001
switch.0002
switch.0003
switch.0004
ROX™ v2.2 User Guide
Description
The Internet
Your Local Network
Demilitarized Zone
The firewall itself
IPSec connections on w1ppp
IPSec connections on w2ppp
Zone
loc
loc
Any
dmz
372
Section 35.5.2, "Working with Firewall
RuggedBackbone™ RX5000
