30. Tunnelling
30.3.3.1. Goose
The forms and tables in this section are located under tunnel/l2tunneld/goose.
Figure 30.30. Goose Tunnel table
This table displays configured GOOSE tunnels.
Figure 30.31. Goose Tunnel form
name
Synopsis: A string
Description of goose tunnel
interface
Synopsis: A string
The interface to listen on for goose frames
multicast-mac
Synopsis: Multicast Ethernet MAC address in colon-separated hexadecimal notation
The multicast MAC address to listen for
Figure 30.32. Remote Daemon of Goose Tunnel table
ip-address
Synopsis: IPv4 address in dotted-decimal notation
The IP address of remote L2 protocol server
30.3.3.2. Generic
The forms and tables in this section are located under tunnel/l2tunneld/generic.
Figure 30.33. Generic L2 Tunnel table
