RuggedCom RuggedWireless RS900W Specification Sheet

The RuggedWireless™ RS900W is an industrially hardened
Ethernet switch which integrates an IEEE 802.11b/g Wireless
Access Point, with a fully managed wired 8-Port Ethernet switch
providing six Fast Ethernet copper only ports and two optional
copper or fiber ports. With the installation of the RS900W
wireless access point, a network designer will achieve the
integration of wired and wireless networks. The RS900W can be
configured as an access, client, or bridge device
Designed to operate reliably in harsh industrial environments the
RS900W provides a high level of immunity to electromagnetic
interference and heavy electrical surges typical of environments
found in electric utility substations, factory floors or in curb side
traffic control cabinets. An operating temperature range of -40°C
to +85°C coupled with hazardous location certification, optional
conformal coating and a galvanized steel enclosure allows the
RS900W to be placed in almost any location.
The RS900W functions as a standalone IEEE 802.11b/g access
point for wireless clients providing wireless data rates of up to
54Mbps. All wireless communications are protected by the very
latest "robust security networks" features including strong
encryption protocols using WPA with TKIP and even
WPA2/802.11i with AES support. Static authentication support is
provided by WPA-PSK. For additional centralized control, the
RS900W also supports IEEE 802.1X/RADIUS for wireless user
traffic and distributing dynamic encryption keys.
The embedded Rugged Operating System (ROSTM) provides
advanced networking features such as Enhanced Rapid
Spanning Tree (eRSTPTM), VLAN, Quality of Service, and a full
array of intelligent functionality and advanced cyber security
features for high network availability and manageability.
The RS900W is backed by a five year warranty and
unsurpassed technical support.
www.RuggedCom.com
RuggedWireless
Wireless Ethernet with Integrated 8-Port Managed Switch
Ethernet Ports
6 - Fast Ethernet ports (10/100BaseTX)
optional 2 - Fast Ethernet ports (10/100BaseTX or 100BaseFX)
Multiple fiber connector types
Cyber Security
WPA (Wi-Fi Protected Access) with TKIP for enhanced
security and encryption
WPA2/802.11i with CCMP for robust security and encryption
IEEE 802.1X/RADIUS using EAP-PEAP for secure
"enterprise class" authentication configuration
Pre-shared Key Mode (PSK) for "personal" mode
authentication configuration
Multi-level user passwords
SSH/SSL encryption
Enable/disable ports, MAC based port security
Port based network access control (802.1x)
VLAN (802.1q ) to segregate and secure network traffic
Radius centralized password management
SNMPv3 encrypted authentication and access security
Rugged Operating System (ROS™) Features
Simple plug and play operation - automatic learning,
negotiation, and crossover detection
RSTP (802.1D-2004) and Enhanced Rapid Spanning Tree
(eRSTP™) network fault recovery (<5ms)
Quality of Service (802.1p) for real-time traffic
VLAN (802.1q) with double tagging and GVRP support
Link aggregation (802.3ad)
IGMP Snooping for multicast filtering
Port Rate Limiting and Broadcast Storm Limiting
Port configuration, status, statistics, mirroring, security
Loss of link management on fiber ports
SNTP time synchronization (client and server)
RuggedRated™ for Reliability in Harsh Environments
Immunity to EMI and heavy electrical surges
Meets IEEE 1613 (electric utility substations)
Exceeds IEC 61850-3 (electric utility substations)
Exceeds IEC 61800-3 (variable speed drive systems)
Exceeds IEC 61000-6-2 (generic industrial)
Exceeds NEMA TS-2 (traffic control equipment)
-40°C to +85°C operating temperature
no fans or moving parts for improved reliability
20 AWG galvanized steel enclosure
DIN or panel mounting options provide secure
mechanical reliability
Universal Power Supply Options
Fully integrated power supply (no external adaptors)
Universal high-voltage range: 88-300VDC or 85-264VAC
Dual low-voltage DC inputs: 24VDC (9-36VDC) or
48VDC (36-72VDC)
Terminal blocks for reliable maintenance
free connections
CSA/UL 60950 safety approved to +85°C
RuggedWireless™ RS900W
TM
RS900W
Features and Benefits
RUGGEDCOM
ISO 9001:2000 ISO 9001:2000 ISO 9001:2000
CERTIFIED
