8
SET MODE

Tone Control

» SET > Tone Control > RX > SSB
MENU
RX HPF/LPF
Sets the cut-off frequencies for the receive audio high-
pass filter and low-pass filter in 100 Hz steps, in the
SSB mode.
L If this item is set, the "RX Bass" and "RX Treble"
items are automatically set to "0."
RX Bass
RX Treble
Sets the bass or treble level of the receive audio.
» SET > Tone Control > RX > AM
MENU
RX HPF/LPF
Sets the cut-off frequencies for the receive audio high-
pass filter or low-pass filter in 100 Hz steps, in the AM
mode.
Selectable ranges:
L If this item is set, the "RX Bass" and "RX Treble"
items are automatically set to "0."
RX Bass
RX Treble
Sets the bass or treble level of the receive audio.
» SET > Tone Control > RX > FM
MENU
RX HPF/LPF
Sets the cut-off frequencies for the receive audio high-
pass filter or low-pass filter in 100 Hz steps, in the FM
mode.
L If this item is set, the "RX Bass" and "RX Treble"
items are automatically set to "0."
FM RX Bass
FM RX Treble
Sets the bass or treble level of the receive audio.
» SET > Tone Control > RX > CW
MENU
» SET > Tone Control > RX > RTTY
MENU
» SET > Tone Control > RX > PSK
MENU
RX HPF/LPF
Sets the cut-off frequencies for the receive audio high-
pass filter or low-pass filter in 100 Hz steps in the CW,
RTTY, and PSK modes.
(Default: – – – – – – – – –)
(Default: 0)
(Default: 0)
(Default: – – – – – – – – –)
(Default: 0)
(Default: 0)
(Default: – – – – – – – – –)
(Default: 0)
(Default: 0)
(Default: – – – – – – – – –)
» SET > Tone Control > TX > SSB
MENU
TX Bass
TX Treble
Sets the bass or treble level of the transmit audio.
TBW (WIDE)
TBW (MID)
TBW (NAR)
Sets the transmission pass bandwidth to wide, mid,
or narrow, by changing the lower and higher cut-off
frequencies.
» SET > Tone Control > TX > AM
MENU
TX Bass
TX Treble
Sets the bass or treble level of the transmit audio.
» SET > Tone Control > TX > FM
MENU
TX Bass
TX Treble
Sets the bass or treble level of the transmit audio.

Function

» SET > Function
MENU
Beep Level
Sets the beep output level.
L If the "Beep (Confirmation)" item is set to "OFF," no
beeps sound.
Beep Level Limit
Selects whether or not to limit the volume up to the
specified level.
Beep (Confirmation)
Turns the Confirmation beep ON or OFF.
L If the "Beep Level" item is set to "0%," no beep sounds.
Band Edge Beep
Turns the Band Edge beep ON or OFF.
Information
L
• If the "Beep Level" item is set to "0%," no beep sounds.
• When you tune into an amateur band's frequency
range, the high Band Edge beep sounds.
• When you tune out of an amateur band's frequency
range, the low Band Edge beep sounds.
8-2
(Default: 0)
(Default: 0)
(Default: 100 – 2900)
(Default: 300 – 2700)
(Default: 500 – 2500)
(Default: 0)
(Default: 0)
(Default: 0)
(Default: 0)
(Default: 50%)
(Default: ON)
(Default: ON)
(Default: ON (Default))
