Specifications; D General; D Transmitter - Icom IC-7610 Basic Manual

11

SPECIFICATIONS

D General

• Frequency coverage (unit: MHz):
Receiver
Transmitter
• Operating modes:
• Number of memory channels:
• Antenna connectors:
• Power supply requirement:
• Operating temperature range:
• Frequency stability:
• Frequency resolution:
• Power consumption:
Receive Standby
Maximum audio
Transmit Maximum power
• Dimensions (projections not included): 340 (W) × 118 (H) × 277 (D) mm, 13.4 (W) × 4.6 (H) × 10.9 (D) in
• Weight (approximate):

D Transmitter

• Transmit output power:
HF and 50 MHz bands
SSB/CW/RTTY/PSK/FM
AM
• Modulation system:
SSB
AM
FM
• Spurious emission:
Harmonics
Out-of-band emission
• Carrier suppression:
• Unwanted sideband suppression:
• Microphone impedance:
0.030000 ~ 60.000000
0.135700 ~ 0.137800
1.800000 ~ 01.999999*
3.500000 ~ 03.999999*
5.255000 ~ 05.405000
7.000000 ~ 07.300000*
10.100000 ~ 10.150000
14.000000 ~ 14.350000
18.068000 ~ 18.168000
21.000000 ~ 21.450000
24.890000 ~ 24.990000
28.000000 ~ 29.700000
50.000000 ~ 54.000000*
* The frequency coverage and guaranteed ranges differ, depending on the
transceiver version.
USB/LSB (J3E), CW (A1A), RTTY (F1B), PSK (G1B),
AM (A3E) and FM (F3E)
101 (including 2 scan edges)
SO-239×2 (antenna impedance: 50 Ω Unbalanced)
13.8 V DC (±15%)
0°C to +50°C, +32°F to +122°F
Less than ±0.5 ppm (0°C to +50°C, +32°F to +122°F)
1 Hz (minimum)
3.0 A
3.5 A
23.0 A
8.5 kg, 18.7 Ib
1~100 W
1~25 W
P.S.N. modulation
Low power modulation
Reactance modulation
Less than –50 dB (HF band)
Less than –63 dB (50 MHz band)
Less than –40 dB (HF band)
Less than –60 dB (50 MHz band)
More than 50 dB
More than 50 dB
600 Ω
11-1
(Only in the European version)
(Only in the USA version)
