Three Levels of Control
Scope of Controls
WVR7200 Installation and Safety Instructions
You control the instrument on three levels:
Frequently changed settings. The front-panel buttons control the most
commonly changed parameters, such as which measurement appears in each
tile. The knobs are used to adjust levels and make selections.
Tile-specific settings. Pop-up menus control parameters that are specific to
the tile in which they are displayed. The pop-up menus control less frequently
changed parameters such as the waveform display mode (for example,
changing the waveform display mode from RGB to YPbPr). To display a
pop-up menu, press and hold a front panel button for about one second. Most
buttons have a related pop-up menu.
Instrument-wide settings. The parameters in the Configuration menu are
instrument-wide settings. The configuration menu controls settings that are
changed only occasionally, such as changing waveform color or setting the
network address.
Some controls are global and affect all tiles, while other controls only affect the
active tile. Generally speaking, if a control is configured by front-panel buttons or
by a pop-up menu, it is tile specific. (Exceptions are the Input buttons, and all
audio features, both of which are global.) If control is configured by the CONFIG
menu, selections are usually global.
Front-Panel Controls
