Power-On and Power-Off Procedure

Power-On and Power-Off Procedure
AC Power Requirements
Power-On
Power-Off
22
This instrument operates from a single-phase power source with the neutral
conductor at or near earth ground. The line conductor is fused for over-current
protection. A protective ground connection through the grounding conductor in
the power cord is essential for safe operation.
The instrument operates from an AC line frequency of 50 or 60 Hz, over the range
of 100-240 Volts, without the need for configuration, except the power cord.
(See page 18, International power cords.) The typical power draw is 140 Watts.
Refer to the WVR7200 Specifications and Performance Verification Technical
Reference on the Product Documentation CD for additional information on power
and environmental requirements.
1. Connect the supplied power cord to the rear-panel power connector.
2. Press the power button on the instrument front-panel and the instrument will
turn on.
NOTE.
The Standby button on the front-panel does not disconnect mains power.
Only the power cord at the rear of the product can disconnect mains power.
Ensure that the power cord is accessible when the product is operating.
1. Press the power button on the instrument front-panel to turn the instrument off.
2. To remove power completely, disconnect the power cord from the rear-panel
of the instrument.
