Basic Installation Procedure

Compatibility of BNC

Most BNC connectors for video equipment, whether 50 Ω or 75 Ω, use a 50 Ω

standard center pin. Some laboratory 75 Ω BNC connectors use a smaller

Center Pins

diameter center pin. The BNC connectors on the instrument are designed to work

with the 50 Ω standard (large diameter) center pins.

NOTE.

Do not use connectors or terminators with non-standard sized center pins.

Using pins that have a smaller diameter could cause intermittent connections.
