Operating Requirements

Environmental Ratings

Table 2: Environmental performance
Category
Temperature Operating
Non Operating
Humidity Operating
Non Operating
Altitude Operating
Non Operating
Cooling
Physical Specifications
Table 3: Physical characteristics
Characteristic
Dimensions Height
Width
Depth
Weight Net
Shipping
Cleaning
8
Standards or description
0 °C to +40 °C
–40 °C to +75 °C
20% to 80% relative humidity (% RH) at up to +40 °C, non-condensing
5% to 90% RH (relative humidity) at up to +60 °C, non-condensing
Up to 9,842 feet (3,000 meters)
Up to 40,000 feet (12,192 meters)
The intake air vents in the front of the instrument must not be blocked and the rear exhaust
vents requires at least 1 inch of clearance. No clearance is required above or below the
instrument.
Standard
1.72 inches (4.37 centimeters)
19 inches (48.26 centimeters)
20.25 inches (51.44 centimeters) (Not including cables)
9.5 pounds (4.31 kilograms), maximum
19 pounds (8.62 kilograms), approximate
Not required for the safe operation of the instrument. However, if you wish to
perform routine cleaning on the exterior of the instrument, refer to the user manual
on the Product Documentation CD that was shipped with your instrument.
