Configuring Ethernet1/0/2... Done.
Configuring Ethernet1/0/3... Done.
[DeviceA-Bridge-Aggregation1] quit
# Configure the device to use the source and destination MAC addresses of packets as the global
link-aggregation load-sharing criteria.
[DeviceA] link-aggregation load-sharing mode source-mac destination-mac
Configure Device B.
2.
Configure Device B using the same instructions that you used to configure Device A.
Verify the configurations.
3.
# Display summary information about all aggregation groups on Device A.
[DeviceA] display link-aggregation summary
Aggregation Interface Type:
BAGG -- Bridge-Aggregation, RAGG -- Route-Aggregation
Aggregation Mode: S -- Static, D -- Dynamic
Loadsharing Type: Shar -- Loadsharing, NonS -- Non-Loadsharing
Actor System ID: 0x8000, 000f-e2ff-0001
AGG
Interface
-------------------------------------------------------------------------------
BAGG1
The output shows that link aggregation group 1 is a load-shared Layer 2 dynamic aggregation group
and it contains three Selected ports.
# Display the global link-aggregation load-sharing criteria on Device A.
[DeviceA] display link-aggregation load-sharing mode
Link-Aggregation Load-Sharing Mode:
destination-mac address, source-mac address
The output shows that all link aggregation groups created on the device perform load sharing based on
source and destination MAC addresses.

Layer 3 static aggregation configuration example

Network requirements
As shown in
Device A and Device B are connected by their Layer 3 Ethernet interfaces Ethernet 1/0/1 through
•
Ethernet 1/0/3.
• Configure a Layer 3 static aggregation group on Device A and Device B, respectively. Configure IP
addresses and subnet masks for the corresponding Layer 3 aggregate interfaces.
Enable traffic to be load-shared across aggregation group member ports based on source and
•
destination IP addresses.
AGG Partner ID
Mode
D 0x8000, 000f-e2ff-0002
Figure 14:
Select Unselect
Ports Ports
3 0
52
Share
Type
Shar
