Print

Logic Analyzer

1-20
nd Quality Products Online at:
Press this key to execute the print function or save the content
displayed in the screen in the USB storage device in a picture file.
If a PictBridge printer is currently connected and the printer is in
idle state, pressing this key will execute the print function. If no
printer but a USB storage device is currently connected, pressing
this key will save the screen content to the USB storage device in
".png" format. You can also press Storage to set the storage type
to picture and press Pic Type to store the screen image in the
specified picture format (bmp, png, jpeg or tiff). When printer and
USB storage device are connected at the same time, the printer
enjoys higher priority.
Press this key to open the logic analyzer control menu. You can turn
on or off any channel or channel group, modify the display size of
the digital channel waveforms, modify the logic threshold of the
digital channel as well as group the 16 digital channels and display
them as a bus. You can also set a label for each digital channel.
Note:
This function is only applicable to the MSO2000A and
MSO2000A-S series oscilloscopes.
