DS2000A
Digital Oscilloscope
Digital Oscilloscope
Wider vertical range(500uV/div ~ 10V/div), lower noise fl oor,
Better for small signal capturing
Bandwidth 70MHz,100MHz,200MHz,300MHz,standard 50Ω input
Max. Sample Rate 2G Sa/s
Standard Memory Depth up to14Mpts,Optional Memory Depth
up to 56Mpts
Innovative "UltraVision" technology
Waveform capture rate up to 50,000 wfs/s
Up to 256 Levels intensity grading waveform display
Up to 65,000 frames Hardware based Real Time waveform,
Record, Replay & Analysis functions(Std.)
A variety of trigger and serial bus decording
functions(RS232,I2C,SPI,CAN)
Built-in 2 Ch Waveform generator (DS2000A-S)
Complete connectivities: USB Host& Device, LAN(LXI), AUX
Compact size, light weight, easy to use
8 inch TFT (800x480) WVGA
DS2000A Series is the new mainstream digital scope to meet the
customer's applications with its innovative technology, industry
leading specifications, powerful trigger functions and broad
analysis capabilities.
Series
Series
Advertisement
Table of Contents
Related Manuals for Rigol DS2000A Series
Summary of Contents for Rigol DS2000A Series
- Page 1 Complete connectivities: USB Host& Device, LAN(LXI), AUX Compact size, light weight, easy to use 8 inch TFT (800x480) WVGA DS2000A Series is the new mainstream digital scope to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad...
- Page 2 DS2000A Series Digital Oscilloscope RUN/STOP/SINGLE Waveform record&replay Independent control for each channel Decoding Product Dimensions: Width X Height X Depth=361.6 mm×179.6 mm×130.8 mm Weight: 3.9 kg ± 0.2 kg(Without Package) Innovative UltraVision technology Deeper Memory Depth (Std.14Mpts,Opt.56Mpts) Higher Waveform Capture Rate (Up to 50,000 wfms/s) Realtime Waveform Record,Replay &...
- Page 3 UltraVision: Deeper memory(Std.14Mpts,Opt.56Mpts) UltraVision: Up to 50,000 wfms/s Waveform capture rate UltraVision:Realtime waveform record,replay,analysis UltraVision: Deeper Memory with Multi-Level intensity function (std.) grading display(Up to 256 levels) Std. serial bus trigger functions(RS232,I2C,SPI) Optional Serial bus decoding function with listing display RIGOL...
- Page 4 Runt Trigger Versatile Trigger Functions Runt, Nth Edge,Setup/Hold … Std. Advanced Math Function Std. Mask Test Function Built-in 2CH Source(DS2000A-S) Arb function of the Built-in 2CH Source (DS2000A-S) Automatic measurements with statistics Complete Connectivity(USB Host,USB Device,LAN,AUX) RIGOL...
- Page 5 RIGOL Probes supported by DS2000A Series: RIGOL Passive Probes RIGOL Active & Current Probes Model Number Tpye Description Model Number Tpye Description BW:DC~300kHz, Current Max.DC:±100A, 1X: DC~7MHz Probe AC P-P:200A,AC RMS:70A High Z 10X:DC~150MHz Compatibility：All RIGOL Scopes. Probe Compatibility： All RIGOL Scopes.
-
Page 6: Specifications
DS2302A/DS2202A : 20 MHz/100 MHz DS2102A/DS2072A : 20 MHz Low Frequency Response ≤5 Hz (on BNC) (AC Coupling, -3dB) Calculated Rise Time DS2302A: 1.2ns DS2202A: 1.8 ns DS2102A: 3.5 ns DS2072A: 5 ns DC Gain Accuracy ±2% full scale RIGOL... - Page 7 5 bit, 6 bit, 7 bit, 8 bit I2C Trigger Trigger Condition Start, Restart, Stop, Missing ACK, Address, Data, A&D Address Bits 7 bit, 8 bit, 10 bit Address Range 0 to 127, 0 to 255, 0 to 1023 Byte Length 1 to 5 RIGOL...
-
Page 8: Math Operation
Sine, Square, Pulse, Ramp, Noise, DC Arbitrary Waveform Sinc, ExpRise, ExpFall, ECG, Gauss, Lorentz, Haversine Sine Frequency Range 0.1 Hz to 25 MHz Flatness ±0.5 dB (relative to 1 kHz) Harmonic Distortion -40 dBc Spurious (non-harmonic) -40 dBc 40 dB RIGOL... -
Page 9: General Specifications
Execution standard EN 61326-1:2006 EN 61326-2-1:2006 Safety UL 61010-1:2004; CAN/CSA-C22.2 NO. 61010-1-2004; EN 61010-1:2001; IEC 61010-1:2001 Note: 1 Typical. 2 Maximum value with 20 ns, single-channel, dots display and auto memory depth. 3 Supporting legs and handle folded, knob height included. 4 Standard configuration. RIGOL... -
Page 10: Ordering Information
RIGOL Technologies, Inc. Product information in this document subject to update without notice. For the latest information about RIGOL's products, applications and services, please contact local RIGOL offi ce or access RIGOL offi cial website: www.rigol.com...
