C-D Connector Pinout

Table 35 Connector C-D Pinout
Pin Row C
C1 GND (FIXED)
C2 GND
C3 USB_SSRX0-
C4 USB_SSRX0+
C5 GND
C6 USB_SSRX1-
C7 USB_SSRX1+
C8 GND
C9 USB_SSRX2-
C10 USB_SSRX2+
C11 GND (FIXED)
C12 USB_SSRX3-
C13 USB_SSRX3+
C14 GND
C15 DDI1_PAIR6+ (*)
C16 DDI1_PAIR6- (*)
C17 RSVD
C18 RSVD
C19 PCIE_RX6+
C20 PCIE_RX6-
C21 GND (FIXED)
C22 PCIE_RX7+
C23 PCIE_RX7-
C24 DDI1_HPD
C25 DDI1_PAIR4+ (*)
C26 DDI1_PAIR4- (*)
C27 RSVD
C28 RSVD
C29 DDI1_PAIR5+ (*)
C30 DDI1_PAIR5- (*)
C31 GND (FIXED)
C32 DDI2_CTRLCLK_AUX+
C33 DDI2_CTRLDATA_AUX-
C34 DDI2_DDC_AUX_SEL
C35 RSVD
C36 DDI3_CTRLCLK_AUX+ (*)
Copyright © 2017 congatec AG
Pin Row D Pin
D1 GND (FIXED) C56
D2 GND C57
D3 USB_SSTX0- C58
D4 USB_SSTX0+ C59
D5 GND C60
D6 USB_SSTX1- C61
D7 USB_SSTX1+ C62
D8 GND C63
D9 USB_SSTX2- C64
D10 USB_SSTX2+ C65
D11 GND (FIXED) C66
D12 USB_SSTX3- C67
D13 USB_SSTX3+ C68
D14 GND C69
D15 DDI1_CTRLCLK_AUX+ C70
D16 DDI1_CTRLDATA_AUX- C71
D17 RSVD C72
D18 RSVD C73
D19 PCIE_TX6+ C74
D20 PCIE_TX6- C75
D21 GND (FIXED) C76
D22 PCIE_TX7+ C77
D23 PCIE_TX7- C78
D24 RSVD C79
D25 RSVD C80
D26 DDI1_PAIR0+ C81
D27 DDI1_PAIR0- C82
D28 RSVD C83
D29 DDI1_PAIR1+ C84
D30 DDI1_PAIR1- C85
D31 GND (FIXED) C86
D32 DDI1_PAIR2+ C87
D33 DDI1_PAIR2- C88
D34 DDI1_DDC_AUX_SEL C89
D35 RSVD C90
D36 DDI1_PAIR3+ C91
Row C Pin Row D
PEG_RX1- (*) D56 PEG_TX1- (*)
TYPE1# D57 TYPE2#
PEG_RX2+ (*) D58 PEG_TX2+ (*)
PEG_RX2- (*) D59 PEG_TX2- (*)
GND (FIXED) D60 GND (FIXED)
PEG_RX3+ (*) D61 PEG_TX3+ (*)
PEG_RX3- (*) D62 PEG_TX3- (*)
RSVD D63 RSVD
RSVD D64 RSVD
PEG_RX4+ (*) D65 PEG_TX4+ (*)
PEG_RX4- (*) D66 PEG_TX4- (*)
RSVD D67 GND
PEG_RX5+ (*) D68 PEG_TX5+ (*)
PEG_RX5- (*) D69 PEG_TX5- (*)
GND (FIXED) D70 GND (FIXED)
PEG_RX6+ (*) D71 PEG_TX6+ (*)
PEG_RX6- (*) D72 PEG_TX6- (*)
GND D73 GND
PEG_RX7+ (*) D74 PEG_TX7+ (*)
PEG_RX7- (*) D75 PEG_TX7- (*)
GND D76 GND
RSVD D77 RSVD
PEG_RX8+ (*) D78 PEG_TX8+ (*)
PEG_RX8- (*) D79 PEG_TX8- (*)
GND (FIXED) D80 GND (FIXED)
PEG_RX9+ (*) D81 PEG_TX9+ (*)
PEG_RX9- (*) D82 PEG_TX9- (*)
RSVD D83 RSVD
GND D84 GND
PEG_RX10+ (*) D85 PEG_TX10+ (*)
PEG_RX10- (*) D86 PEG_TX10- (*)
GND D87 GND
PEG_RX11+ (*) D88 PEG_TX11+ (*)
PEG_RX11- (*) D89 PEG_TX11- (*)
GND (FIXED) D90 GND (FIXED)
PEG_RX12+ (*) D91 PEG_TX12+ (*)
TCKLm10 63/71
