Table 24 General Purpose Serial Interface Signal Descriptions; Table 25 Power And Gnd Signal Descriptions - Congatec COM Express conga-TC175 User Manual

Signal Pin # Description
WAKE0# B66 PCI Express wake up signal.
WAKE1# B67 General purpose wake up signal. May be used to implement wake-up on PS/2 keyboard or mouse
activity.
BATLOW# A27 Battery low input. This signal may be driven low by external circuitry to signal that the system
battery is low, or may be used to signal some other external power-management event.
THRM# B35 Input from off-module temp sensor indicating an over-temp situation.
THERMTRIP# A35 Active low output indicating that the CPU has entered thermal shutdown.
SMB_CK B13 System Management Bus bidirectional clock line.
SMB_DAT# B14 System Management Bus bidirectional data line.
SMB_ALERT# B15 System Management Bus Alert – active low input can be used to generate an SMI# (System
Management Interrupt) or to wake the system.
LID# A103 Lid button. Used by the ACPI operating system for a LID switch.
SLEEP# B103 Sleep button. Used by the ACPI operating system to bring the system to sleep state or to wake it
up again.
Table 24 General Purpose Serial Interface Signal Descriptions
Signal Pin #
SER0_TX A98
SER1_TX A101
SER0_RX A99
SER1_RX A102
Table 25 Power and GND Signal Descriptions
Signal Pin #
VCC_12V A104-A109
B104-B109
VCC_5V_SBY B84-B87
VCC_RTC A47
GND A1, A11, A21, A31, A41, A51, A57,
A60, A66, A70, A80, A90, A100,
A110, B1, B11, B21, B31, B41, B51,
B60, B70, B80, B90, B100, B110
Copyright © 2017 congatec AG
Description
General purpose serial port transmitter
General purpose serial port transmitter
General purpose serial port receiver
General purpose serial port receiver
Description
Primary power input: +12V nominal. All available VCC_12V pins on the connector(s)
shall be used.
Standby power input: +5.0V nominal. If VCC5_SBY is used, all available VCC_5V_SBY
pins on the connector(s) shall be used. Only used for standby and suspend functions.
May be left unconnected if these functions are not used in the system design.
Real-time clock circuit-power input. Nominally +3.0V.
Ground - DC power and signal and AC signal return path.
All available GND connector pins shall be used and tied to Carrier Board GND plane.
I/O
I 3.3VSB
I 3.3VSB
I 3.3VSB
I 3.3V
O 3.3V
I/O 3.3VSB PU 2k2 3.3VSB
I/O OD
3.3VSB
I 3.3VSB
I OD 3.3V
I OD 3.3V
I/O
O 3.3V
O 3.3V
I 3.3V
I 3.3V
TCKLm10
PU/PD Comment
PU 1k 3.3VSB
PU 10k 3.3VSB
PU 10k 3.3VSB
PU 10k 3.3V
PU 10k 3.3V
PU 2k2 3.3VSB
PU 2k2 3.3VSB
PU 10k 3.3VSB
PU 10k 3.3VSB
PU/PD Comment
PU 47k 3.3V
PU 47k 3.3V
I/O PU/PD Comment
P
P
P
P
