8.1

COM Express Connector Pinout

Table 14 COM Express Connector Pinouts
Pin Row A
A1 GND(FIXED)
A2 GBE0_MDI3-
A3 GBE0_MDI3+
A4 GBE0_LINK100#
A5 GBE0_LINK1000#
A6 GBE0_MDI2-
A7 GBE0_MDI2+
A8 GBE0_LINK#
A9 GBE0_MDI1-
A10 GBE0_MDI1+
A11 GND(FIXED)
A12 GBE0_MDI0-
A13 GBE0_MDI0+
A14 GBE0_CTREF (*)
A15 SUS_S3#
A16 SATA0_TX+
A17 SATA0_TX-
A18 SUS_S4#
A19 SATA0_RX+
A20 SATA0_RX-
A21 GND(FIXED)
A22 USB_SSRX0-
A23 USB_SSRX0+
A24 SUS_S5#
A25 USB_SSRX1-
A26 USB_SSRX1+
A27 BATLOW#
A28 (S)ATA_ACT#
A29 HDA_SYNC
A30 HDA_RST#
A31 GND(FIXED)
A32 HDA_BITCLK
A33 HDA_SDOUT
A34 BIOS_DIS0#
A35 THRMTRIP#
A36 USB6-
Copyright © 2017 congatec AG
Pin Row B Pin Row A
B1 GND(FIXED) A56 RSVD
B2 GBE0_ACT# A57 GND
B3 LPC_FRAME# A58 PCIE_TX3+
B4 LPC_AD0 A59 PCIE_TX3-
B5 LPC_AD1 A60 GND(FIXED)
B6 LPC_AD2 A61 PCIE_TX2+
B7 LPC_AD3 A62 PCIE_TX2-
B8 LPC_DRQ0# (*) A63 GPI1
B9 LPC_DRQ1# (*) A64 PCIE_TX1+
B10 LPC_CLK A65 PCIE_TX1-
B11 GND(FIXED) A66 GND
B12 PWRBTN# A67 GPI2
B13 SMB_CK A68 PCIE_TX0+
B14 SMB_DAT A69 PCIE_TX0-
B15 SMB_ALERT# A70 GND(FIXED)
B16 SATA1_TX+ A71 eDP_TX2+/LVDS_A0+
B17 SATA1_TX- A72 eDP_TX2-/LVDS_A0-
B18 SUS_STAT# A73 eDP_TX1+/LVDS_A1+
B19 SATA1_RX+ A74 eDP_TX1-/LVDS_A1-
B20 SATA1_RX- A75 eDP_TX0+/LVDS_A2+
B21 GND(FIXED) A76 eDP_TX0-/LVDS_A2-
B22 USB_SSTX0- A77 eDP/LVDS_VDD_EN
B23 USB_SSTX0+ A78 LVDS_A3+
B24 PWR_OK A79 LVDS_A3-
B25 USB_SSTX1- A80 GND(FIXED)
B26 USB_SSTX1+ A81 eDP_TX3+/LVDS_A_CK+
B27 WDT A82 eDP_TX3-/LVDS_A_CK-
B28 HDA_SDIN2 (*) A83 eDP_AUX+/LVDS_I2C_CK
B29 HDA_SDIN1 (*) A84 eDP_AUX-/LVDS_I2C_DAT
B30 HDA_SDIN0 (**) A85 GPI3
B31 GND(FIXED) A86 RSVD
B32 SPKR A87 eDP_HPD
B33 I2C_CK A88 PCIE_CLK_REF+
B34 I2C_DAT A89 PCIE_CLK_REF-
B35 THRM# A90 GND(FIXED)
B36 USB7 A91 SPI_POWER
Pin Row B
B56 RSVD
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND(FIXED)
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67 WAKE1#
B68 PCIE_RX0+
B69 PCIE_RX0-
B70 GND(FIXED)
B71 DDI0_PAIR0+
B72 DDI0_PAIR0-
B73 DDI0_PAIR1+
B74 DDI0_PAIR1-
B75 DDI0_PAIR2+
B76 DDI0_PAIR2-
B77 DDI0_PAIR4+ (*)
B78 DDI0_PAIR4- (*)
B79 eDP/LVDS_BKLT_EN
B80 GND(FIXED)
B81 DDI0_PAIR3+
B82 DDI0_PAIR3-
B83 eDP/LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 DD0_HPD
B90 GND(FIXED)
B91 DDI0_PAIR5+ (*)
MA50m17 41/60
