5.1.9

VGA

The Intel Kaby Lake ULT SoC does not natively support VGA interface. However, the conga-TC175 can support this interface by integrating an
®
optional DisplayPort to VGA adapter chip.
Note
For VGA support, you need a customized conga-TC175 variant.
5.1.10

LVDS/eDP

The conga-TC175 offers an LVDS interface with optional eDP overlay on the AB connector. The LVDS interface provides LVDS signals by default,
but can optionally support eDP signals (assembly option). For more information, contact congatec technical center.
The LVDS interface supports:
• single or dual channel LVDS (color depths of 18 bpp or 24 bpp)
• integrated flat panel interface with clock frequency up to 112 MHz
• VESA and OpenLDI LVDS color mappings
• automatic panel detection via Embedded Panel Interface based on VESA EDID
• resolution up to 1920x1200 in dual LVDS bus mode
Note
The LVDS/eDP interface supports either LVDS or eDP signals. Both signals are not supported simultaneously.
5.1.11

General Purpose Serial Interface

The conga-TC175 offers two UART interfaces via the congatec Board Controller. These interfaces support up to 1 MBps and can operate in
low-speed, full-speed and high-speed modes. They do not support hardware handshake and flow control.
The UART interfaces require congatec driver to function.
