Sm Bus - Congatec COM Express conga-TC175 User Manual

Bus Number (hex)
07h (Note3)
08h (Note3)
Note
1. In the standard configuration, the Intel Management Engine (ME) related devices are partly present or not present at all.
2. The PCI Express ports are visible only if a device is attached to the PCI Express slot on the carrier board.
3. The table represents a case when a single functional PCI/PCIe device is connected to all possible slots on the carrier board. The given bus
numbers will change based on actual hardware configuration.
4. Internal PCI devices not connected to the conga-TC175 are not listed.
9.3 I C
2
Onboard resources are not connected to the I²C bus. Address 16h is reserved for congatec Battery Management solutions.
9.4

SM Bus

System Management (SM) bus signals are connected to the Intel
management devices. For more information about this subject contact congatec technical support.
Copyright © 2017 congatec AG
Device Number (hex) Function Number (hex)
00h 00h
00h 00h
Description
PCI Express Port 6
PCI Express Port 7
® chipset. The SM bus is not intended to be used by off-board non-system
TCKLm10 68/71
