C commands
Group
Syntax
Related Commands
Arguments
Examples
88
The CURVe command transfers waveform data from an external device to the
instrument. The data is stored in the waveform location specified by
DATa:DESTination, starting with the data point specified by DATa:STARt. Only
one waveform can be transferred at a time. The waveform will only be displayed
if the reference waveform is displayed.
Refer to Waveform Commands for a description of the waveform transfer
process. Waveform command group
Waveform
CURVe {<Block>|<asc curve>}
CURVe?
DATa on page 89, DATa:STARt
WFMInpre? on page 248,
page 257, HEADer on page 141
<Block> is the waveform data in binary format. The waveform is formatted as:
#<x><yyy><data><newline>, where:
<x> is the number of y bytes. For example, if <yyy>=500, then <x>=3.
<yyy> is the number of bytes to transfer if samples are one or two bytes wide.
Use the WFMInpre:BYT_Nr command to set the width for waveforms
transferred into the instrument. Use WFMOutpre:BYT_Nr to set the width for
waveforms transferred out from the instrument.
<data> is the curve data.
<newline> is a single byte new line character at the end of the data.
<asc curve> is the waveform data in ASCII format. The format for ASCII data is
<NR1>[,<NR1>...] where each <NR1> represents a data point.
CURVe? with ASCII encoding, start and stop of 1 and 10 respectively, and a
width set to 1 might return the following ASCII data:
:CURVE 61,62,61,60,60,-59,-59,-58,-58,-59.
on page 30
on page 92, DATa:STOP
WFMInpre:BYT_Nr on page 250,
on page 93,
WFMOutpre? on
