TRIGger:A:PULSE:Width?

Group
Syntax
Examples

TRIGger:A:PULse:WIDth:POLarity

Group
Syntax
Arguments
Examples
TBS2000 Series Programmer
Queries the width for the pulse-width trigger. Query only.
Trigger
TRIGger:A:PULSEWidth?
TRIGger:A:PULSEWidth? might
return :TRIGGER:A:PULSEWIDTH:POLARITY POSITIVE;WHEN
LESSTHAN;WIDTH 8.0E-9
Sets or queries the polarity for the pulse width trigger. This is equivalent to
setting the Polarity option in the Pulse Trigger menu.
Trigger
TRIGger:A:PULse:WIDth:POLarity {NEGative|POSitive}
TRIGger:A:PULse:WIDth:POLarity?
POSITIVe polarity specifics pulses with a rising leading edge.
NEGAtive polarity specifies pulses with a falling leading edge.
TRIGGER:A:PULSEWIDTH:POLARITY NEGATIVE sets the pulse polarity to
negative.
TRIGGER:A:PULSEWIDTH:POLARITY? might
return :TRIGGER:A:WIDTH:POLARITY POSITIVE indicating a positive pulse.
T commands
233
