Wfmoutpre:bit_Nr - Tektronix TBS2000 Series Programmer's Manual

W commands

WFMOutpre:BIT_Nr

Group
Syntax
Related commands
Arguments
258
Sets and queries the number of bits per waveform point that outgoing waveforms
contain, as specified by the DATa:SOUrce command. Changing the value of
WFMOutpre:BIT_Nr also changes the values of WFMInpre:FILTERFreq and
DATa:WIDth.
Waveform
WFMOutpre:BIT_Nr <NR1>
WFMOutpre:BIT_Nr?
DATa:SOUrce on page 91,
<NR1> is the number of bits per data point and can be 8 or 16.
Examples
WFMOUTPRE:BIT_NR 16 sets the number of bits per waveform point to 16 for
outgoing waveforms.
WFMOUTPRE:BIT_NR? might return :WFMOUTPRE:BIT_NR 8 indicating
that outgoing waveforms use 8 bits per waveform point.
DATa:WIDth on page 94
TBS2000 Series Programmer
