Math command group

Measurement command group

TBS2000 Series Programmer
Math commands provide math function definition.
Table 17: Math commands
Command
on page 165
MATH?
MATH:DEFINE on page 166
on page 167
MATH:HORizontal:POSition
MATH:HORizontal:SCALe on page 167
MATH:HORizontal:UNIts on page 168
on page 169
MATH:VERtical:POSition
MATH:VERtical:SCAle on page 169
MATH:VERTical:UNIts on page 170
Measurement commands control the automated measurement system. The
instrument can display up to six automated measurements. In the commands,
these measurement readouts are named MEAS<x>, where <x> can be 1, 2, 3, 4,
5, or 6.
The best method for taking measurements over the computer interface is to use
the MEASUREMENT:IMMED commands and queries. The immediate
measurement has no front-panel equivalent, and the instrument never displays
immediate measurements.
Because they are computed only when they are requested, immediate
measurements slow the waveform update rate less than displayed measurements.
Use the VALue? query to obtain measurement results of either displayed or
immediate measurements.
Several measurement commands set and query measurement parameters. You
can assign some parameters, such as waveform sources, differently for each
measurement readout.
Command groups
Description
Returns the definition for the math waveform.
Performs the specified mathematical operation
on the input signal or signals.
Sets or returns the horizontal position of the
math waveform.
Sets or returns the horizontal scale of the math
waveform.
Sets or returns the math horizontal
measurement units label.
Sets or returns the math waveform display
position.
Sets or returns the math waveform display scale
in units per division.
Sets or returns the math vertical measurement
units label.
